Bussmannn LP-CC-8 - Low-Peak Time-Delay Fuse 8A 600V (200kA AIC)

Bussmannn LP-CC-8 is a Low-Peak time-delay fuse designed for circuit protection in low-voltage applications. It features a 600V AC/DC rating with an 8A current capacity and 200kA interrupting rating at 600V for reliable overcurrent protection. The compact cylindrical design measures 1-1/2 inches in length with a 0.41-inch diameter and 1 lb weight, constructed to UL-248-4 and CSA Class 1422-02 standards. Certified to CE/UL-248-4 Guide JDDZ and CSA Class 1422-02, this Class CC fuse is commonly used in industrial control panels, motor circuits, and transformer protection.

Key Features & Specifications

• Type: LP-CC time-delay fuse with single barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 8A
• Dimensions: 1-1/2 in length x 0.41 in diameter
• Standards: CE/UL-248-4 Guide JDDZ, CSA Class 1422-02
• Applications: Industrial control panels, motor circuits, transformer protection
• Class Rating: CC
• AIC rating: 200kA@600V
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712180399
• GTIN: 00051712180399
