Bussmannn LP-CC-4-1/2 - Low-Peak Fuse 4A 600V (200kA AIC)

Bussmannn LP-CC-4-1/2 is a Low-Peak time-delay fuse designed for circuit protection in low-voltage applications, featuring a 4A current rating and 600V voltage rating. Its compact 1-1/2-inch cylindrical design with a 0.41-inch diameter and Class CC rating provides reliable protection against short circuits and overloads, certified to UL-248-4 and CSA Class 1422-02 standards. The fuse offers a 200kA interrupting capacity at 600V, with a single-barrel construction for efficient current limitation in industrial control circuits, motor loads, and transformer protection.

Key Features & Specifications

• Type: LP-CC time-delay fuse with low peak characteristics
• Voltage Rating: 600V AC/DC
• Current Rating: 4A
• Dimensions: 1-1/2 in length, 0.41 in diameter
• Weight: 1 lb
• Class Rating: CC
• AIC Rating: 200kA @ 600V
• Certification: CE/UL-248-4, CSA Class 1422-02
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712180368
• GTIN: 00051712180368
