Eaton Bussmann LP-CC-3-1/2 - Class CC Time-Delay Fuse 3A 600V (200kA AIC)

Eaton Bussmann LP-CC-3-1/2 is a Low-Peak time-delay fuse designed for protecting control circuits, motors, and transformers against overcurrent conditions. It features a 600V AC voltage rating with a 3A current rating and 200kA interrupting capacity at 600V for reliable circuit protection. The fuse measures 1-1/2 inches in length with a 0.41-inch diameter and single-barrel construction, weighing 1 lb for industrial durability. It complies with UL 248-4, CSA Class 1422-02, and CE standards, ensuring safety and performance reliability. Typical applications include industrial control panels, motor branch circuits, and transformer protection where time-delay characteristics prevent nuisance tripping during temporary overloads.

Key Features & Specifications

• Type: Low-Peak time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 3A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL 248-4, CSA Class 1422-02, CE certified
• Applications: Control circuits, motor protection, transformer circuits
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Family: Low-Peak
• Country of Origin: Mexico

Product Identification

• UPC: 005171218030
• GTIN: 00051712180306
