Eaton Bussmann LP-CC-2-8/10 - Class CC Time-Delay Fuse 2A 600V (200kA AIC Rating)

Eaton Bussmann LP-CC-2-8/10 is a Low-Peak time-delay fuse designed for comprehensive circuit protection in industrial applications. It features a 2A current rating and 600V voltage rating with exceptional 200kA interrupting capacity at rated voltage. The fuse measures 1-1/2 inches in length with a 0.41-inch diameter and utilizes a single-barrel construction weighing 1 lb. Certified to UL-248-4 and CSA Class 1422-02 standards, this Class CC fuse provides reliable protection for control circuits, transformers, and motor loads across various industrial environments.

Key Features & Specifications

• Type: Low-Peak time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 2A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL-248-4, CSA Class 1422-02, CE marked
• Applications: Control circuits, transformers, motor protection
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Family: Low-Peak
• Item Subcategory: Low Voltage Fuse
• Country of Origin: Mexico

Product Identification

• UPC: 051712180559
• GTIN: 00051712180559
