Eaton Bussmann LP-CC-2-1/4 - Class CC Time-Delay Fuse 2A 600V (200kA AIC Rating)

Eaton Bussmann LP-CC-2-1/4 is a Low-Peak time-delay fuse designed for protecting control circuits, motors, and transformers by providing superior short-circuit and overload protection. It features a 2A current rating and 600V voltage rating with an impressive 200kA interrupting capacity at 600V AC. The fuse construction includes a single barrel design with 0.41 inch diameter and 1-1/2 inch length, weighing 1 lb, utilizing current-limiting technology to safely interrupt fault currents. This Class CC fuse complies with UL 248-4, CSA Class 1422-02, and CE standards for industrial safety requirements. Typical applications include motor branch circuits, control transformers, and industrial control panels where reliable circuit protection is critical.

Key Features & Specifications

• Type: Low-Peak time-delay fuse, current-limiting design with single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 2A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL 248-4, CSA Class 1422-02, CE certified
• Applications: Control circuits, motor protection, transformer circuits
• AIC rating: 200kA @ 600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Family: Low-Peak
• Country of Origin: Mexico

Product Identification

• UPC: 005171218050
• GTIN: 00051712180504
