Eaton Bussmann LP-CC-12 - Class CC Time-Delay Fuse 12A 600V (200kA AIC)

Eaton Bussmann LP-CC-12 is a Low-Peak time-delay, current-limiting fuse designed for protecting control circuits, transformers, and motors. It features a 12A current rating and a 600V AC voltage rating, housed in a compact 1-1/2 inch long body with a 0.41-inch diameter and a single barrel construction. This fuse is certified to UL 248-4 and CSA Class 1422-02 standards and offers a high 200kA interrupting rating at 600V AC. Its typical industrial applications include motor branch circuit protection and the safeguarding of electrical components where high fault currents may be present.

Key Features & Specifications

• Type: Low-Peak, time-delay, current-limiting, Class CC fuse
• Voltage Rating: 600V AC
• Current Rating: 12A
• Dimensions: 1-1/2 in length, 0.41 in diameter
• Standards: CE, UL 248-4, CSA Class 1422-02
• Applications: Control circuit, transformer, and motor protection
• AIC rating: 200kA @ 600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb

Product Identification

• UPC: 051712180252
• GTIN: 00051712180252
