LP-CC-1-6/10 Eaton Bussmann Series 1.6A Class CC Fuse

LP-CC-1-6/10 Eaton Bussmann Series 1.6A Class CC Fuse

LP-CC-1-6/10 is the exact Eaton number for a 1.6 A Low-Peak Class CC fuse with time-delay and current-limiting operation.

Its ratings cover 600 Vac service and 300 Vdc service, with separate interrupt capacities for AC and DC circuits.

Common Applications

• Identifying a 1.6 A fuse for specialized circuits
• Protecting branch circuits within the published ratings
• Supporting industrial control and panel equipment
• Handling small motor and relay circuit inrush
• Pairing with an appropriate isolated in-line holder

Key Features

• Exact fractional catalog code: LP-CC-1-6/10 corresponds to 1.6 A
• Time-delay behavior: At least 12 seconds at twice rated current
• Class CC format: Compact 0.41 in x 1.5 in cylindrical body
• High fault rating: Interrupts up to 200 kA under the stated 600 Vac condition
• Ordering identifiers: Exact UPC and EAN are manufacturer verified

Specifications

• Amperage: 1.6 A
• Voltage: 600 Vac and 300 Vdc
• Fuse category: Class CC
• Element count: Two
• Response: Current-limiting time delay
• AC interrupt rating: 200 kA at 600 Vac
• DC interrupt rating: 20 kA at 300 Vdc
• Indicator: None
• Termination: Ferrule end x ferrule end
• Material: Melamine tube
• Measurements: 1.5 x 0.41 x 0.41 in
• Product weight: 0.15 lb

Product Identification

• Exact part: LP-CC-1-6/10
• Maker: Eaton
• Series name: Bussmann Low-Peak LP-CC
• UPC code: 051712180481
• EAN code: 5027590172974

FAQ

What does LP-CC-1-6/10 identify?

This code selects the 1.6 A fuse in Eaton's Bussmann Low-Peak LP-CC family.

Is the fuse rated for both AC and DC?

Yes. The exact Eaton record gives 600 Vac and 300 Vdc voltage ratings.

Why is the rejection feature important?

With the proper fuse block, it prevents use of a lesser-rated supplementary fuse.

Which certifications are listed?

Eaton identifies the item as UL Listed and CSA Certified, with CE and RoHS compliance also stated.

Does the catalog number include the slash?

Yes. Eaton presents the full identifier as LP-CC-1-6/10.
