Eaton Bussmann LP-CC-1-1/8 - Class CC Fuse 1A (200kA AIC @600V)

Eaton Bussmann LP-CC-1-1/8 is a Class CC low-voltage current-limiting fuse designed for protecting control circuits, transformers, and motors. It features a 1A current rating and 600V voltage rating with a high 200kA interrupting capacity at 600V AC. The fuse construction includes a single barrel design with 0.41 inch diameter and 1-1/2 inch length, weighing 1 lb. It complies with UL 248-4, CSA Class 1422-02, and CE standards for safety and performance. Typical applications include industrial control panels, motor branch circuits, and transformer protection where current limitation is critical.

Key Features & Specifications

• Type: Low-Peak Class CC current-limiting fuse, single barrel
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL 248-4, CSA Class 1422-02, CE certified
• Applications: Control circuits, transformer protection, motor circuits
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Family: Low-Peak
• Country of Origin: Mexico

Product Identification

• UPC: 051712180443
• GTIN: 00051712180443
