Eaton Bussmann LP-CC-1-1/2 - Class CC Fuse 1A 600V (200kA AIC Rating)

Eaton Bussmann LP-CC-1-1/2 is a Class CC low-voltage current-limiting fuse designed for circuit protection in industrial control systems and equipment. It features a 1A current rating and 600V AC voltage rating with a high 200kA interrupting capacity at 600V for reliable fault protection. The fuse construction includes a single-barrel design measuring 1-1/2 inches in length with a 0.41-inch diameter and weighs 1 lb. It complies with UL 248-4, CSA Class 1422-02, and CE standards for safety and performance. Typical applications include protection of control circuits, transformers, and motor controllers where space-saving Class CC fuses are required.

Key Features & Specifications

• Type: Class CC low-peak current-limiting fuse, single barrel
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL 248-4, CSA Class 1422-02, CE
• Applications: Industrial control circuits, transformers, motor controllers
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Family: Low-Peak
• Country of Origin: Mexico

Product Identification

• UPC: 051712180474
• GTIN: 00051712180474
