Edison Fuses LENRK1.25 - Class RK1 1.25A Time-Delay Fuse (250VAC)
Edison Fuses LENRK1.25 - Class RK1 1.25A Time-Delay Fuse (250VAC)

Edison Fuses LENRK1.25 - Class RK1 1.25A Time-Delay Fuse (250VAC)

Edison Fuses
Price
Save $-19.66
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Edison Fuses LENRK1.25 is a 1.25A, 250VAC/125VDC time-delay, dual-element, Class RK1 cartridge fuse designed for overcurrent protection in motor circuits and other inductive loads. This fuse provides a 200,000A interrupting rating (AIC) at 250VAC, with a compact 2-inch length and 0.56-inch diameter, constructed with a glass tube and nickel-plated brass end caps. It meets UL 248-12 and CSA C22.2 No. 248.12 standards for branch circuit protection. Typical applications include motor control centers, panelboards, and industrial equipment requiring high fault current protection and motor starting surge tolerance.

Key Features & Specifications
  • Type: Class RK1, time-delay, dual-element, cartridge fuse
  • Voltage Rating: 250 VAC / 125 VDC
  • Current Rating: 1.25 A
  • Dimensions: 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
  • Standards: UL 248-12, CSA C22.2 No. 248.12
  • Applications: Motor circuits, transformers, solenoids, industrial control panels
  • AIC rating: 200,000 A at 250 VAC
  • Fuse Class: RK1
  • Mounting: Clip center
  • Weight: 0.001 lb


Product Identification
  • UPC: 78263453804
  • GTIN: 00782634538042
