Square D LAL36225MB - Molded Case Breaker 225A 600V
Square D LAL36225MB - Molded Case Breaker 225A 600V

Square D LAL36225MB - Molded Case Breaker 225A 600V

Square D
Price
Save $589.39
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D LAL36225MB is a three-pole molded case circuit breaker from Schneider Electric's LAL Series, designed to provide thermal-magnetic overcurrent protection for industrial power distribution systems. It is rated for 600V AC, 225A continuous current, and delivers a 30kA interrupting capacity at 480V, with long-time and instantaneous trip functions for coordinated fault response. This feed-thru connection breaker measures 11 inches in height, 6 inches in width, and 5.84 inches in depth, weighing 16.16 lb, and is constructed for three-phase applications. It complies with industry standards for molded case circuit breakers, ensuring reliable performance in demanding environments. Typical applications include main or feeder protection in industrial switchboards, panelboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 225A
  • Dimensions: 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
  • Weight: 16.16 lb
  • Poles: 3
  • Phase: 3
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC Rating: 30kA@480V
  • Family: LAL Series
  • Country of Origin: Mexico
  • Manufacturer: Schneider Electric
  • Item Subcategory: Molded Case


Product Identification
  • UPC: 7.85901E+11
