Bussmann KTK-R-6/10 - Class CC Fuse 6A 600V (200kA AIC Rating)

The Bussmann KTK-R-6/10 is a Class CC low-voltage current-limiting fuse designed to provide reliable overcurrent protection in industrial electrical systems. It features a 6A current rating and 600V voltage rating with an impressive 200kA interrupting capacity at 600V for high-fault current protection. The fuse construction utilizes a single-barrel design with 0.41-inch diameter and 1-1/2-inch length, weighing 1 lb for compact panel mounting. This LIMITRON series fuse meets CE/UL-248-4 and CSA Class 1422-02 standards, ensuring compliance with industry safety requirements. Typical applications include protection of control circuits, transformers, and motor controllers where space-efficient, high-performance circuit protection is essential.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 6A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Applications: Control circuits, transformers, motor controllers
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Weight: 1 lb
• Family: LIMITRON
• Country of Origin: Mexico

Product Identification

• UPC: 051712420501
• GTIN: 00051712420501
