Bussmann KTK-R-3/10 - Class CC Fuse 3A 600V (200kA AIC)

Bussmann KTK-R-3/10 is a Class CC, fast-acting LIMITRON fuse designed for overcurrent protection in low-voltage circuits up to 600V AC. It features a 3A current rating with a 200kA interrupting capacity at rated voltage, housed in a compact 1-1/2" cylindrical body with 0.41" diameter and 1 lb weight. The fuse meets UL-248-4, CSA Class 1422-02, and CE standards, constructed with a single-barrel design for reliable performance in industrial control panels, motor circuits, and transformer protection applications.

Key Features & Specifications

• Type: Fast-acting Class CC fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 3A
• Dimensions: 1-1/2" length x 0.41" diameter
• Weight: 1 lb
• Standards: UL-248-4, CSA Class 1422-02, CE
• Applications: Industrial control panels, motor circuits, transformer protection
• AIC rating: 200kA@600V
• Class Rating: CC
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Country of Origin: Mexico

Product Identification

• UPC: 051712420556
• GTIN: 00051712420556
