Eaton Bussmann KTK-R-1/4 - Class CC Fuse 1A 600V (200kA AIC Rating)

Eaton Bussmann KTK-R-1/4 is a Class CC low-voltage current-limiting fuse designed for circuit protection in industrial control applications. It provides reliable overcurrent protection with a 1A current rating and 600V voltage rating, featuring a compact single-barrel construction measuring 1-1/2 inches in length with a 0.41-inch diameter. The fuse meets CE/UL-248-4 Guide JDDZ and CSA Class 1422-02 standards and offers 200kA interrupting capacity at 600V. Typical applications include protection of control circuits, transformers, and motor controllers in industrial environments.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: CE/UL-248-4 Guide JDDZ, CSA Class 1422-02
• Applications: Industrial control circuits, transformers, motor controllers
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 1 lb
• Certification: CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
• Family: LIMITRON

Product Identification

• UPC: 051712420549
• GTIN: 00051712420549
