Eaton Bussmann KTK-R-1/10 - Class CC Fuse 1A 600V (200kA AIC Rating)

Eaton Bussmann KTK-R-1/10 is a current-limiting fuse designed for protecting sensitive electrical components and control circuits from short-circuit and overload conditions. It features a 600V AC voltage rating with a 1A current rating and provides 200kA interrupting capacity at 600V for reliable circuit protection. The fuse has a compact 1-1/2 inch body length with 0.41 inch diameter and single barrel construction, weighing 1 lb for straightforward installation. It complies with UL-248-4, CSA Class 1422-02, and CE standards, ensuring industry-recognized safety performance. Typical applications include industrial control panels, motor control centers, and electrical distribution systems requiring Class CC protection.

Key Features & Specifications

• Type: Current-limiting time-delay fuse, Class CC rating
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL-248-4, CSA Class 1422-02, CE certified
• Applications: Control circuits, motor protection, industrial panels
• AIC rating: 200kA@600V
• Barrels: 1
• Class Rating: CC
• Weight: 1 lb
• Family: LIMITRON
• Country of Origin: Mexico

Product Identification

• UPC: 051712420518
• GTIN: 00051712420518
