Bussmann KRPC2001SP - Class R Fuse 200A 600V
Bussmann KRPC2001SP - Class R Fuse 200A 600V

Bussmann KRPC2001SP - Class R Fuse 200A 600V

Bussmann
Price
Save $-628.41
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Bussmann KRPC2001SP is a Class R current-limiting fuse designed for primary protection of motor circuits and feeders against short circuits and overloads. This 200-amp, 600-volt AC/DC rated fuse provides high interrupting capacity to safely clear fault currents up to 200,000 amperes RMS symmetrical. Constructed with a melamine tube and silver-plated blade terminals, the fuse features a compact 2.75-inch diameter by 7.88-inch length body for easy installation in standard fuse holders. It complies with UL 248-9 and CSA C22.2 No. 248.9 standards for Class RK1 fuses, ensuring reliable performance in industrial environments. Typical applications include motor control centers, panelboards, and branch circuit protection in manufacturing and processing facilities.

Key Features & Specifications
  • Type: Class R current-limiting fuse, melamine tube construction, silver-plated blade terminals
  • Voltage Rating: 600V AC/DC
  • Current Rating: 200A
  • Dimensions: 2.75" diameter x 7.88" length
  • Standards: UL 248-9, CSA C22.2 No. 248.9
  • Applications: Motor circuit protection, feeder protection, panelboard protection
  • Fuse Class: RK1
  • Interrupting Rating: 200kA RMS symmetrical
  • Mounting: Clip or bolted connection
  • Weight: 5.19 lb


Product Identification
  • UPC: 5171217847
  • GTIN: 00051712178471
