Burndy KPB4CG1 - Compression Connector 600V (Tin-Plated Copper)
Burndy KPB4CG1 - Compression Connector 600V (Tin-Plated Copper)

Burndy KPB4CG1 - Compression Connector 600V (Tin-Plated Copper)

Burndy
Price
Save $-7.01
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Burndy KPB4CG1 is a compression connector designed for terminating and splicing copper conductors in industrial power distribution systems. It is rated for a maximum voltage of 600V and accommodates a current range determined by the conductor size, with a wire size range of #4 AWG to 600 kcmil. The connector features a tin-plated copper construction, measures 0.99 inches in width by 1.0 inches in length, and weighs 5.19 lb. It is UL Listed and complies with applicable industry standards for safety and performance. This connector is commonly used in panelboards, switchboards, and motor control centers for reliable, low-resistance connections.

Key Features & Specifications
  • Type: Compression connector, tin-plated copper, one-hole barrel
  • Voltage Rating: 600V AC/DC
  • Current Rating: Dependent on conductor size
  • Dimensions: 0.99 in x 1.0 in
  • Standards: UL Listed
  • Applications: Power distribution, panelboards, switchboards, motor control centers
  • Wire Size: #4 AWG to 600 kcmil
  • Metal Type: Copper, tin-plated
  • Connection: Compression
  • Barrels: Single
  • Mounting: One-hole
  • Certification: UL Listed
  • Country of Origin: United States
  • Weight: 5.19 lb


Product Identification
  • UPC: 781810100233
  • GTIN: 07818101002333
