Eaton Bussmann KLU-650 - RK1 Class Fuse 650A (200kA AIC)

Bussmann
Price
Save $-217.64
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton Bussmann KLU-650 is a low-voltage, current-limiting fuse designed for high-amperage circuit protection in industrial power distribution systems. It features a 650A current rating and a 600V voltage rating, providing a 200kA interrupting capacity at rated voltage to safely clear high-level faults. The fuse is constructed as a single-barrel, RK1 class device with a 2.4-inch diameter and bolt-in connection terminals, housed within a robust package measuring 8.63 x 2.5 x 2.5 inches and weighing 3.75 lb. It is engineered to meet stringent industry standards for reliable performance in demanding applications such as service entrance equipment, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Low-voltage, current-limiting, RK1 class fuse with single-barrel construction and bolt-in connection
  • Voltage Rating: 600V AC
  • Current Rating: 650A
  • Dimensions: 8.63 in L x 2.5 in H x 2.5 in W (219.2mm x 63.5mm x 63.5mm)
  • Standards: Designed to meet applicable industry standards for circuit protection
  • Applications: Service entrance equipment, industrial switchboards, motor control centers, and power distribution panels
  • AIC rating: 200kA @ 600V
  • Connection: Bolt-In
  • Barrels: 1
  • Class Rating: RK1
  • Diameter: 2.4 in (61mm)
  • Weight: 3.75 lb (1.7 kg)


Product Identification
  • UPC: 005171213503
  • GTIN: 00051712135030
