Bussmann KBC-350 - Low Voltage Fuse 350A (200kA AIC)

Bussmann
Price
Save $318.96
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann KBC-350 is a low-voltage current-limiting fuse designed for protecting industrial power distribution circuits and equipment from short-circuit faults. It features a 350A current rating and a 600V voltage rating, with a high 200kA interrupting capacity at rated voltage. The fuse is constructed as a single-barrel unit with stud connections, measuring 6.182 in long with a 1.5 in diameter, and is compliant with UL, CE, and RoHS standards. Typical applications include service entrance equipment, motor control centers, and switchgear where reliable high-fault current protection is required.

Key Features & Specifications
  • Type: KBC Series, Low Voltage, Current-Limiting, Stud Connection
  • Voltage Rating: 600V AC
  • Current Rating: 350A
  • Dimensions: 6.182 in L x 2 in H x 2 in W (156.9mm x 50.8mm x 50.8mm)
  • Standards: UL Recognized, CE Marked, RoHS Compliant
  • Applications: Power Distribution, Switchgear, Motor Protection
  • AIC rating: 200kA @ 600V
  • Connection: Stud
  • Barrels: 1
  • Diameter: 1.5 in (38.1 mm)
  • Weight: 0.8 lb (0.36 kg)
  • Certification: UL Recognized, CE Marked, RoHS Compliant


Product Identification
  • UPC: 051712493505
  • GTIN: 00051712493505
