Bussmann KBC-250 - Low Voltage Fuse 250A (200kA@600V AIC Rating)

Bussmann KBC-250 is a low-voltage current-limiting fuse designed for industrial circuit protection applications requiring high interrupting capacity. It features a 250A current rating and 600V voltage rating with an impressive 200kA interrupting capacity at rated voltage. The fuse measures 6.182 inches in length with a 1.5-inch diameter and utilizes stud-type connections in a single-barrel configuration. Certified to UL Recognized, RoHS Compliant, and CE Marked standards, this Eaton KBC Series fuse provides reliable protection for industrial power distribution systems, motor circuits, and other critical electrical equipment where high fault current interruption is essential.

Key Features & Specifications

• Type: KBC Series current-limiting fuse with stud connection, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 250A
• Dimensions: 6.182" L × 2" H × 2" W (157mm × 51mm × 51mm)
• Standards: UL Recognized, RoHS Compliant, CE Marked
• Applications: Industrial power distribution, motor circuit protection, high fault current interruption
• AIC Rating: 200kA@600V
• Connection: Stud type
• Barrels: 1
• Diameter: 1.5 inches (38.1mm)
• Weight: 1 lb (0.45kg)
• Certification: UL Recognized, RoHS Compliant, CE Marked
• Family: KBC Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712492508
• GTIN: 00051712492508
