Bussmannn KBC-125 - Low Voltage Fuse 125A (200kA@600V Interrupt Rating)

Bussmannn KBC-125 is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 600V AC/DC voltage rating and 125A current capacity with a 200kA interrupting rating at 600V for reliable fault isolation. The compact 1.58" x 1.6" x 4.61" (40.1mm x 40.6mm x 117.1mm) stud-mount design with 1.22" diameter barrel provides robust construction using copper alloy elements. Compliant with UL/CSA standards, this KBC series fuse is engineered for switchgear, motor control centers, and power distribution systems requiring 600V protection.

Key Features & Specifications

• Type: KBC series low-voltage current-limiting fuse with copper alloy elements
• Voltage Rating: 600V AC/DC
• Current Rating: 125A
• Dimensions: 1.58" L x 1.6" H x 4.61" W (40.1mm x 40.6mm x 117.1mm)
• Standards: UL/CSA listed
• Applications: Industrial switchgear, motor control centers, power distribution
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA@600V
• Diameter: 1.22" (31mm)
• Weight: 1 lb (0.45kg)
• Country of Origin: Mexico

Product Identification

• UPC: 051712491259
• GTIN: 00051712491259
