Bussmann KAC-60 - Low Voltage Fuse 60A (200kA AIC @600V)

The Bussmann KAC-60 is a low-voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with a 60A current rating and delivers exceptional 200kA interrupting capacity at rated voltage. The fuse construction utilizes a single-barrel design with stud connections and measures 4-3/8 inches in length with a 0.81-inch diameter, weighing 1 lb for substantial physical presence. Certified to UL and CE standards, this Mexico-manufactured component meets rigorous international safety requirements. Typical applications include motor branch circuits, feeder protection, and industrial control panels where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: KAC Series current-limiting fuse with single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 60A
• Dimensions: 4-3/8" length x 0.81" diameter
• Standards: UL Recognized, CE Certified
• Applications: Industrial power distribution, motor protection, feeder circuits
• AIC rating: 200kA@600V
• Connection: Stud
• Barrels: 1
• Weight: 1 lb
• Certification: CE, UL Recognized
• Family: KAC Series
• Item Subcategory: Low Voltage Fuse

Product Identification

• UPC: 051712470605
• GTIN: 00051712470605
