Bussmann KAC-50 - Current-Limiting Fuse 50A (200kA Interrupting Rating)

Bussmann KAC-50 is a low-voltage current-limiting fuse designed for industrial circuit protection applications requiring high interrupting capacity. This 50A rated fuse operates at 600V AC with an impressive 200kA interrupting rating, providing reliable short-circuit protection in demanding environments. The fuse features a rugged single-barrel construction with stud connections and measures 4-3/8 inches in length with a 0.81-inch diameter, weighing 1 lb for robust industrial use. It carries comprehensive certifications including UL Recognition (File 60314), CSA Certification (LR12636), and CE compliance, meeting industry standards for safety and performance. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where high fault current protection is essential.

Key Features & Specifications

• Type: KAC Series current-limiting fuse with single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 50A
• Dimensions: 4-3/8 inches length, 0.81 inches diameter
• Standards: UL Recognized (File 60314, Guide JFHR2), CSA Certified (LR12636), CE
• Applications: Industrial motor circuits, feeder protection, control panels
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA@600V
• Weight: 1 lb
• Certification: CE, UL Recognized, Guide JFHR2, File 60314, CSA Certified LR12636

Product Identification

• UPC: 051712470506
• GTIN: 00051712470506
