Bussmann KAC-40 - Low Voltage Fuse 40A (200kA AIC @600V)

Bussmann KAC-40 is a low-voltage current-limiting fuse designed for circuit protection in industrial power distribution systems. It features a 600V AC rating with a 40A current capacity and 200kA interrupting rating at 600V for reliable short-circuit protection. The fuse measures 4.32" in height with a 0.81" diameter stud connection barrel, constructed with UL Recognized and CE Marked components for compliance with North American and European standards. Its compact 0.76" × 0.76" × 4.32" form factor makes it suitable for panelboards, switchgear, and motor control centers requiring high interrupting capacity protection.

Key Features & Specifications

• Type: KAC series current-limiting fuse with single barrel stud connection
• Voltage Rating: 600V AC
• Current Rating: 40A
• Dimensions: 4.32" height × 0.76" width × 0.76" length
• Weight: 1 lb
• Diameter: 0.81"
• Standards: UL Recognized, CE Marked
• AIC Rating: 200kA @ 600V
• Connection: Stud terminal
• Barrels: 1
• Family: KAC Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712470407
• GTIN: 00051712470407
