Bussmann KAC-15 - Current-Limiting Fuse 15A 600V (200kA AIC Rating)

Bussmann KAC-15 is a low-voltage current-limiting fuse designed for industrial circuit protection applications. It features a 600V AC voltage rating with a 15A current rating, providing reliable overcurrent protection in demanding environments. The fuse measures 2.84 inches in height with a 0.56-inch diameter and utilizes stud-type connections for secure installation. Certified to UL and CE standards, this fuse meets rigorous safety requirements and offers a 200kA interrupting rating at 600V AC for high-fault current protection. Typical applications include industrial control panels, motor circuits, and power distribution systems where robust circuit protection is essential.

Key Features & Specifications

• Type: KAC Series current-limiting fuse with stud connection
• Voltage Rating: 600V AC
• Current Rating: 15A
• Dimensions: 2.84" height × 0.5" width × 0.5" length
• Diameter: 0.56 inches
• Weight: 1 lb
• Standards: UL Recognized, CE Marked
• AIC Rating: 200kA @ 600V AC
• Connection: Stud type
• Barrels: 1
• Applications: Industrial control panels, motor protection, power distribution systems
• Family: KAC Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712470155
• GTIN: 00051712470155
