Siemens JXD23B225 - Molded Case Circuit Breaker 225A 3P (65kA AIC)
Siemens JXD23B225 - Molded Case Circuit Breaker 225A 3P (65kA AIC)

Siemens JXD23B225 - Molded Case Circuit Breaker 225A 3P (65kA AIC)

Siemens
Price
Save $9,456.03
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Siemens JXD23B225 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 225A current rating and a 240V voltage rating, housed within a compact 400A/JD frame measuring 8.661" x 12.992" x 6.696" (220mm x 330mm x 170mm) and weighing 18.301 lb. This thermal-magnetic breaker complies with UL and IEC standards and is RoHS compliant, operating effectively in temperatures from -25°C to 70°C. It is engineered for integration into SB switchboards and Sentron panelboards, offering a high interrupting capacity of 65kA at 240V for robust system protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection with Long Time and Instantaneous Trip Functions
  • Voltage Rating: 240V AC
  • Current Rating: 225A
  • Frame Size: 400A/JD
  • AIC Rating: 65kA @ 240V
  • Poles: 3
  • Phase Connection: ABC
  • Connection: Bolt-On
  • Terminal Connection: Lug (500 MCM, lugs not included)
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 8.661" x 12.992" x 6.696" (220mm x 330mm x 170mm)
  • Weight: 18.301 lb
  • Standards & Certification: RoHS, UL, IEC
  • Panel Type: Compatible with SB Switchboards (without lugs) and Sentron Panelboards
  • Breaker Type: Standard
  • Additional Info: Lugs are not included


Product Identification
  • UPC: 783643212930
  • GTIN: 00783643212930
