Siemens JXD22B300 - Molded Case Breaker 300A 240V 2-Pole
Siemens JXD22B300 - Molded Case Breaker 300A 240V 2-Pole

Siemens JXD22B300 - Molded Case Breaker 300A 240V 2-Pole

Siemens
Price
Save $3,680.56
/
Condition
  • Low stock - 8 items left
  • Backordered, shipping soon
Call for Price
The Siemens JXD22B300 is a 2-pole molded case circuit breaker from the Sentron Series, designed for thermal magnetic protection in 1-phase power distribution systems. It is rated for 300A at 240VAC with a 65kA interrupting capacity at 240V, utilizing LI (Long-Time and Instantaneous Trip) functions for overcurrent protection. This bolt-on breaker measures 8.661 x 12.992 x 6.699 inches, weighs 15.099 lb, and features a 400A/JD frame size with lug terminal connections for 500 MCM wire, though it does not include lugs. It complies with RoHS standards and holds UL and IEC certifications, operating within a temperature range of -13°F to 158°F (-25°C to 70°C). Typical applications include use in SB Switchboards Without Lugs and Sentron Panelboards for industrial and commercial power distribution.

Key Features & Specifications
  • Type: Molded Case, Standard Breaker
  • Voltage Rating: 240V
  • Current Rating: 300A
  • Dimensions: 8.661 x 12.992 x 6.699 inches
  • Standards: RoHS, UL, IEC
  • Applications: SB Switchboards Without Lugs, Sentron Panelboards
  • Switch Type: Not specified
  • Configuration: 2-Pole
  • Coil Voltage Maximum: Not applicable
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: Not specified
  • Phase: 1
  • Voltage: 240V
  • Amperage: 300A
  • AIC rating: 65kA@240V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: 400A/JD
  • Trip Type: Thermal Magnetic
  • Panel Type: SB Switchboards Without Lugs, Sentron Panelboards
  • Breaker Type: Standard
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: 500 MCM
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not specified
  • Class Rating: Not specified
  • Diameter: Not specified
  • Velocity: Not specified
  • Clip Center: Not specified
  • Clas: Not specified
  • Mounting: Bolt-On
  • Hz: Not specified
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not specified
  • Bucket Style: Not specified
  • Bucket Type: Not specified
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 300A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Not specified
  • Wire Size: 500 MCM
  • Certification: UL, IEC
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Lug
  • Frequency Rating: Not specified
  • Phase Connection: Not Applicable
  • Standards: RoHS
  • Compatible Frames: 400A/JD
  • Installation Type: Bolt-On
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: JD
  • Current Rating: 300A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 783643212893
  • GTIN: 00783643212893
