Littelfuse JTD600ID - Class J Time-Delay Fuse 600A 600V (200kA AIC)
JTD600ID Littelfuse JTD_ID Series - UL Class J Time-Delay Fuses with Indication Low Voltage Fuse 600V 600A Fuse - Essential Electric Supply
JTD600ID Littelfuse JTD_ID Series - UL Class J Time-Delay Fuses with Indication Low Voltage Fuse 600V 600A Fuse - Essential Electric Supply
JTD600ID Littelfuse JTD_ID Series - UL Class J Time-Delay Fuses with Indication Low Voltage Fuse 600V 600A Fuse - Essential Electric Supply
JTD600ID Littelfuse JTD_ID Series - UL Class J Time-Delay Fuses with Indication Low Voltage Fuse 600V 600A Fuse - Essential Electric Supply
Littelfuse JTD600ID - Class J Time-Delay Fuse 600A 600V (200kA AIC)

Littelfuse JTD600ID - Class J Time-Delay Fuse 600A 600V (200kA AIC)

Littelfuse
Price
Save $680.54
/
Title
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Littelfuse JTD600ID is a UL Class J time-delay fuse with visual indication designed for circuit protection in industrial power distribution systems. It features a 600V AC rating and 600A current capacity with a 200kA interrupting rating at 600V for high-fault current protection. The bolt-in fuse measures 1.13" in diameter with a rugged construction meeting UL 248-8 and CSA standards. Its time-delay characteristics provide motor circuit protection while the indicator pin offers visible fault confirmation. Typical applications include industrial control panels, motor starter circuits, and power distribution equipment requiring Class J protection.

Key Features & Specifications
  • Type: JTD_ID Series UL Class J Time-Delay Fuse with Indication
  • Voltage Rating: 600V AC
  • Current Rating: 600A
  • Dimensions: 1.13" diameter
  • Standards: UL 248-8 Listed / CSA Certified
  • Applications: Industrial power distribution, motor protection
  • Class Rating: J
  • Connection: Bolt-In
  • Barrels: 1
  • AIC rating: 200kA@600V
  • Weight: 3 lb
  • Country of Origin: Mexico
Product Identification
  • UPC: 07945803193
  • GTIN: 00079458031935
