Littelfuse JTD080 is a low-voltage, time-delay fuse designed for robust circuit protection in industrial power distribution systems. It provides a 600V AC/DC voltage rating with an 80A current rating and a 200kA interrupting capacity to handle high fault currents. The fuse features a bolt-in connection, a 1.13-inch diameter, and a 4-5/8 inch length, constructed to meet stringent UL 248-8 Class J standards. It is certified by UL, CSA, and CE for safety and reliability, making it suitable for protecting motors, transformers, and feeders where time-delay characteristics are required to withstand inrush currents.

Key Features & Specifications
  • Type: Low Voltage, Time-Delay (TD), Bolt-In Fuse, Class J
  • Voltage Rating: 600V AC/DC
  • Current Rating: 80A
  • Dimensions: 4-5/8 in Length, 1.13 in Diameter
  • Standards: UL 248-8 Class J, UL Listed, CSA Certified, CE
  • Applications: Industrial power distribution, motor protection, transformer protection
  • AIC Rating: 200kA
  • Connection: Bolt-In
  • Class Rating: J
  • Weight: 5.19 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 079458202229
  • GTIN: 00079458202229
