Bussmann JKS-70 - Class J Time-Delay Fuse 70A (200kA AIC @600V)

Bussmann JKS-70 is a Class J time-delay fuse designed for comprehensive circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with a 70A current rating, providing reliable overcurrent protection with high interrupting capacity. The fuse construction includes a single-barrel design measuring 1.13 inches in diameter with an overall length of 4-5/8 inches and weighs 1.29 lb, featuring robust materials for durable performance. It complies with UL 248-8, CSA Class 1422-02, and CE standards, ensuring industry-recognized safety and reliability. Typical applications include motor branch circuits, transformers, and feeder protection in industrial facilities where high fault current interruption is critical.

Key Features & Specifications

• Type: Class J time-delay fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 70A
• Dimensions: 4-5/8 inches length, 1.13 inches diameter
• Standards: UL 248-8, CSA Class 1422-02, CE certified
• Applications: Motor protection, transformer circuits, industrial power distribution
• AIC rating: 200kA @ 600V AC
• Class Rating: J
• Barrels: 1
• Weight: 1.29 lb
• Family: Limitron
• Country of Origin: China

Product Identification

• UPC: 051712630702
• GTIN: 00051712630702
