Eaton Bussmann JKS-350 - Class J Fuse 350A 600V (200kA AIC)

Bussmann
Price
Save $1,756.77
/
Title
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Eaton Bussmann JKS-350 is a Class J time-delay fuse designed for branch circuit protection in industrial power distribution systems. It provides a 350A current rating and a 600V AC voltage rating for reliable overcurrent protection. The fuse features a single-barrel construction with a 2.11-inch diameter and a body length of 7.13 inches, weighing 1.85 lb. It is certified to UL 248-8 and CSA Class 1422-02 standards, offering an interrupting rating of 200,000 amperes at 600V AC for high-fault current applications in motor control centers, panelboards, and industrial machinery.

Key Features & Specifications
  • Type: Class J, time-delay, low-voltage power fuse, single barrel
  • Voltage Rating: 600V AC
  • Current Rating: 350A
  • Dimensions: 7.13 in L x 2 in H x 2 in W (181.1 mm x 50.8 mm x 50.8 mm)
  • Standards: CE, UL 248-8 (Guide JDDZ), CSA Class 1422-02
  • Applications: Industrial branch circuit protection, motor control centers, panelboards
  • AIC Rating: 200 kA @ 600V
  • Class Rating: J
  • Diameter: 2.11 in (53.6 mm)
  • Weight: 1.85 lb (0.84 kg)
  • Barrels: 1
  • Family: Limitron


Product Identification
  • UPC: 051712633505
  • GTIN: 00051712633505
