Bussmann JKS-100 - Class J Time-Delay Fuse 100A 600V

Bussmann
Price
Save $232.99
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Bussmann JKS-100 is a Class J time-delay fuse designed for branch circuit protection in industrial power distribution systems. It features a 100A current rating and a 600V AC voltage rating, providing a high 200kA interrupting capacity to safely clear severe fault currents. The fuse is constructed as a single-barrel device with a 1.13-inch diameter and an overall length of 4.63 inches, weighing 0.29 lb. It is certified to UL 248-8 and CSA C22.2 No. 248-8 standards, ensuring reliable performance for protecting motor circuits, feeders, and other equipment where withstanding inrush currents is critical.

Key Features & Specifications
  • Type: Class J, time-delay (Limitron), low-voltage power fuse
  • Voltage Rating: 600V AC
  • Current Rating: 100 Amps
  • Dimensions: 4.63 in L x 1.13 in H x 1.13 in W
  • Standards: UL 248-8, CSA C22.2 No. 248-8, CE
  • Applications: Motor branch circuit protection, feeder protection, industrial power distribution
  • AIC rating: 200,000 Amps at 600V AC
  • Class Rating: J
  • Barrels: 1
  • Diameter: 1.13 inches
  • Weight: 0.29 lb


Product Identification
  • UPC: 051712631006
  • GTIN: 00051712631006
