Bussmann JJS-80 - T-Class Fuse 80A (200kA Interrupting Rating)

Bussmann JJS-80 is a time-delay, low-voltage fuse designed for comprehensive circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with an 80A current rating, providing reliable overload and short-circuit protection. The fuse measures 0.75 inches in diameter with a compact single-barrel construction and weighs 1 lb, built with robust materials for industrial environments. It complies with UL 248-15 and CSA Class 1422-02 standards, ensuring safety and reliability. Typical applications include motor branch circuits, transformers, and feeder protection in commercial and industrial facilities.

Key Features & Specifications

• Type: Time-delay, low-voltage fuse with single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 80A
• Dimensions: 0.75" diameter
• Standards: UL 248-15, CSA Class 1422-02, CE certified
• Applications: Motor circuits, transformers, feeder protection
• AIC rating: 200kA@600V
• Class Rating: T
• Family: T-Tron
• Weight: 1 lb
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712628808
• GTIN: 00051712628808
