Bussmann JJS-40 - Class T Fuse 40A 600V (200kA AIC Rating)

Bussmann JJS-40 is a Class T low-voltage fuse designed for high-interrupting capacity circuit protection in industrial applications. It features a 40A current rating and 600V voltage rating with a 200kA interrupting capacity at 600V AC. The fuse construction includes a single-barrel design with 0.81-inch diameter and 1-9/16-inch length, weighing 1 lb for robust performance. It meets CE, UL 248-15 Guide JDDZ, and CSA Class 1422-02 standards for safety and reliability. Typical applications include motor branch circuits, feeder circuits, and service entrance equipment requiring high fault current protection.

Key Features & Specifications

• Type: Class T low-voltage fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 40A
• Dimensions: 1-9/16 inch length, 0.81 inch diameter
• Standards: CE, UL-248-15 Guide JDDZ, CSA Class 1422-02
• Applications: Motor branch circuits, feeder circuits, service entrance equipment
• AIC rating: 200kA@600V
• Class Rating: T
• Barrels: 1
• Weight: 1 lb
• Family: T-Tron
• Country of Origin: Mexico

Product Identification

• UPC: 051712628402
• GTIN: 00051712628402
