Bussmann JJS-225 - Class T Time-Delay Fuse 225A 600V

Bussmann
Price
Save $617.66
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann JJS-225 is a low-voltage, time-delay fuse designed for branch circuit and feeder protection in industrial power distribution systems. It features a 225A current rating and a 600V AC voltage rating, providing a high 200kA interrupting capacity at rated voltage for reliable short-circuit protection. The fuse is constructed as a single-barrel, Class T device with a 1-inch diameter and overall dimensions of 3.63 x 1 x 1 inches, weighing 0.55 lb. It complies with CE, UL 248-15 (Guide JDDZ), and CSA Class 1422-02 standards, ensuring suitability for demanding applications such as motor control centers, service entrance equipment, and industrial panelboards.

Key Features & Specifications
  • Type: Low-voltage, time-delay (T-Tron family), single-barrel fuse
  • Voltage Rating: 600V AC
  • Current Rating: 225A
  • Dimensions: 3.63 in L x 1 in H x 1 in W
  • Standards: CE, UL-248-15 Guide JDDZ, CSA Class 1422-02
  • Applications: Industrial power distribution, branch circuit & feeder protection, motor control centers
  • AIC rating: 200kA @ 600V
  • Class Rating: T
  • Diameter: 1 in
  • Barrels: 1
  • Weight: 0.55 lb


Product Identification
  • UPC: 051712628228
  • GTIN: 00051712628228
