Square D JGL36175C - 3-Pole 175A Molded Case Breaker (600V, 35kA)
Square D JGL36175C - 3-Pole 175A Molded Case Breaker (600V, 35kA)

Square D JGL36175C - 3-Pole 175A Molded Case Breaker (600V, 35kA)

Square D
Price
Save $2,792.57
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D JGL36175C is a three-pole molded case circuit breaker from the Powerpact family, designed to provide thermal-magnetic protection for industrial electrical systems. It is rated for 600V AC, 175A, and 35kA at 480V, with a J frame size and LI (long-time and instantaneous) trip functions. This feed-thru connection breaker measures 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm), weighs 4.5 lb, and accepts wire sizes from 4 AWG to 4/0 AWG (Cu/Al) via lug terminals. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, operating within a temperature range of 28-158 °F (-2-70 °C) and featuring a CBA phase connection. This breaker is suitable for three-phase applications requiring reliable overcurrent protection in commercial and industrial power distribution panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, Powerpact J Frame
  • Voltage Rating: 600V AC
  • Current Rating: 175A
  • Dimensions: 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (H x W x D)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Three-phase industrial power distribution, overcurrent protection
  • Poles: 3
  • Connection: Feed-Thru
  • Terminal Connection: Lug
  • Wire Size: 4 AWG to 4/0 AWG (Cu/Al)
  • AIC Rating: 35kA@480V
  • Phase: 3
  • Phase Connection: CBA
  • Functions: LI - Long-Time and Instantaneous
  • Protection: Thermal Magnetic
  • Temp Rating: 28-158 °F (-2-70 °C)
  • Weight: 4.5 lb
  • Certification: UL, CSA, NOM
  • Country of Origin: United States


Product Identification
  • UPC: 785901583226
