Cutler Hammer JGE3100AAG is a three-pole molded case circuit breaker from the Series G family, designed to provide LI (Long-Time and Instantaneous) protection for industrial electrical systems. This thermal magnetic breaker is rated for 600V AC, 100A continuous current, and delivers an interrupting capacity of 25kA at 480V, with a three-phase feed-thru connection. The unit measures 3.44 inches in depth, 7 inches in height, and 4.13 inches in width, weighing 6 lb, and is constructed for panelboard or switchboard installation. It complies with applicable UL and NEMA standards for overcurrent protection in commercial and industrial power distribution. Typical applications include motor control centers, lighting panels, and main or branch feeder circuits in manufacturing facilities and data centers.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 3.44 in x 7 in x 4.13 in (Length/Depth x Height x Width)
  • Standards: UL, NEMA
  • Applications: Industrial power distribution, motor control centers, lighting panels
  • Switch Type: Feed-Thru
  • Configuration: 3-Pole, 3-Phase
  • Coil Voltage Maximum: Not applicable (thermal magnetic)
  • Temp Rating: Standard industrial
  • Shipping Dimensions: 3.44 in x 7 in x 4.13 in
  • Phase: 3
  • Voltage: 600V
  • Amperage: 100A
  • AIC rating: 25kA@480V
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: JGE
  • Trip Type: Thermal Magnetic
  • Panel Type: Standard
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Standard
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Standard
  • Inductance: Not applicable
  • Impedance: Not specified
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Panelboard/Switchboard
  • Hz: 50/60
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: 100A
  • Dist Voltage: 600V
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 100A
  • Full Load Amp Minimum: 100A
  • Enclosure: Open
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 100A
  • Amperage Minimum: 100A
  • Nema Rating: Standard
  • Switch Style: Feed-Thru
  • Wire Size: Not specified
  • Certification: UL
  • Circuit Breaker Mounting Style: Fixed
  • Terminal Connection: Feed-Thru
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Standards: UL, NEMA
  • Compatible Frames: Series G
  • Installation Type: Panelboard/Switchboard
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: JGE
  • Current Rating: 100A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: Standard
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 78211488619
  • GTIN: 00782114886199
