Square D JGA36200SA - PowerPacT J 200A 3-Pole Breaker (600VAC)
Square D JGA36200SA - PowerPacT J 200A 3-Pole Breaker (600VAC)

Square D JGA36200SA - PowerPacT J 200A 3-Pole Breaker (600VAC)

Square D
Price
Save $1,563.39
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Square D JGA36200SA is a PowerPacT J thermal-magnetic circuit breaker designed to protect electrical systems from overloads and short circuits. This 3-pole, 200A unit is rated for 600VAC and 250VDC, offering interrupting capacities of 65kAIC at 240VAC, 35kAIC at 480VAC, and 18kAIC at 600VAC. The breaker features an I-Line style plug-in connection, accepts wire sizes from AWG 3/0 to 350 kcmil for aluminum or copper terminals, and measures 7.5 in x 4.09 in x 3.4 in (191 mm x 104 mm x 86 mm) with a weight of 5 lb. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, operating within a temperature range of -13 to 158 °F (-25 to 70 °C). This breaker is suitable for industrial applications requiring reliable overcurrent protection in three-phase power distribution systems.

Key Features & Specifications
  • Type: PowerPacT J thermal-magnetic circuit breaker
  • Voltage Rating: 600VAC, 250VDC
  • Current Rating: 200A
  • Dimensions: 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution and protection
  • Switch Type: Circuit breaker
  • Configuration: 3-pole
  • Coil Voltage Maximum: Not applicable
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Shipping Dimensions: Not specified
  • Phase: 3
  • Voltage: 600VAC, 250VDC
  • Amperage: 200A
  • AIC rating: 65kAIC at 240VAC, 35kAIC at 480VAC, 18kAIC at 600VAC
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: JGA
  • Trip Type: Thermal-magnetic
  • Panel Type: Not specified
  • Breaker Type: PowerPacT J
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not specified
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not specified
  • Mounting: I-Line plug-in
  • Hz: Not specified
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: AWG 3/0...350 kcmil
  • Amperage Maximum: 200A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Not applicable
  • Wire Size: AWG 3/0...350 kcmil aluminium/copper terminals
  • Certification: UL, CSA, NOM
  • Circuit Breaker Mounting Style: I-Line plug-in
  • Terminal Connection: I-Line Style Plug-In
  • Frequency Rating: Not specified
  • Phase Connection: 3-phase
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Compatible Frames: JGA
  • Installation Type: Plug-in
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: JGA
  • Current Rating: 200A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 785901947165
  • GTIN: 785901947165
