Bussmann JDN-80E - Medium Voltage Fuse 80A (15,500V Class E)

Bussmann JDN-80E is a medium voltage fuse designed for overcurrent protection in high-voltage electrical systems. It features a 15,500V voltage rating and 80A current rating for robust circuit protection. The fuse utilizes a single-barrel ferrule connection design with a 3-inch diameter and 15-inch clip center spacing, constructed for reliable performance in demanding environments. It complies with Class E standards for medium voltage applications, ensuring proper interruption characteristics. This fuse is typically employed in industrial power distribution, motor protection, and transformer circuits where medium voltage protection is required.

Key Features & Specifications

• Type: Medium Voltage Fuse, Class E, Single Barrel
• Voltage Rating: 15,500V AC
• Current Rating: 80A
• Dimensions: 3" Diameter, 15" Clip Center
• Standards: Class E Rated
• Applications: Industrial Power Distribution, Motor Protection, Transformer Circuits
• Connection: Ferrule
• Barrels: 1
• Class Rating: E
• Weight: 10 lb

Product Identification

• UPC: 005171214433
• GTIN: 00051712144339
