Square D JDL36150SA - Molded Case Circuit Breaker 150A 600V
Square D JDL36150SA - Molded Case Circuit Breaker 150A 600V

Square D JDL36150SA - Molded Case Circuit Breaker 150A 600V

Square D
Price
Save $855.18
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D JDL36150SA is a three-pole, 150A molded case circuit breaker from the PowerPact J family, designed for overcurrent protection and remote switching in industrial power systems. It operates at 600VAC with a thermal magnetic trip unit providing long-time and instantaneous trip functions, and includes a 110/120Vac shunt trip for remote operation. The unit measures 7.5 in (191 mm) in height, 4.09 in (104 mm) in width, and 3.4 in (86 mm) in depth, weighs 5 lb, and features a feed-thru connection with AWG 4 to AWG 4/0 aluminum/copper terminal compatibility. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, and is certified by UL, CSA, and NOM. This circuit breaker is suited for commercial and industrial AC power systems requiring reliable overload and short-circuit protection.

Key Features & Specifications
  • Manufacturer: Schneider Electric
  • Item Subcategory: Molded Case
  • Family: Powerpact
  • Type: JDL
  • Poles: 3
  • Current Rating: 150A
  • Voltage Rating: 600V
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Connection: Feed-Thru
  • Wire Size: AWG 4...AWG 4/0 aluminium/copper terminal
  • AIC rating: 18kA@480V
  • Phase: 3
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Dimensions: 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight: 5 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification: UL, CSA, NOM
  • Additional Info: complete with 110/120Vac shunt trip


Product Identification
  • UPC: 785901630630
  • GTIN: 00785901630630
