Bussmann HVW-8 - Medium Voltage Fuse 8A 1200V (Class E Rated)

Bussmann HVW-8 is a medium voltage fuse designed for overcurrent protection in high-voltage electrical systems. It features a 1200V voltage rating and an 8A current rating, providing reliable circuit interruption. The fuse is constructed as a single-barrel unit with a 0.41-inch diameter and weighs 5.19 lb, built to Class E specifications for industrial applications. It meets industry standards with an interrupting rating of 1250kVA at 2.5kV, ensuring compliance with electrical protection requirements. Typical applications include motor control centers, transformers, and industrial power distribution systems where medium voltage protection is critical.

Key Features & Specifications

• Type: Medium Voltage Fuse, HVW Series, Single Barrel Construction
• Voltage Rating: 1200V AC
• Current Rating: 8A
• Dimensions: 0.41-inch Diameter
• Standards: Class E Rated
• Applications: Industrial Power Distribution, Motor Control Centers, Transformer Protection
• AIC Rating: 1250kVA @ 2.5kV
• Weight: 5.19 lb
• Family: HV Series

Product Identification

• UPC: 05171272094
• GTIN: 00051712720946
