Cutler Hammer HQP3015HV - 1-Pole 15A 240V Circuit Breaker
Cutler Hammer HQP3015HV - 1-Pole 15A 240V Circuit Breaker

Cutler Hammer HQP3015HV - 1-Pole 15A 240V Circuit Breaker

Cutler Hammer
Price
Save $377.79
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Cutler Hammer HQP3015HV is a high-voltage molded case circuit breaker designed for primary overcurrent and short-circuit protection in industrial power distribution systems. It is rated for 240V AC and 15 amps, providing reliable interruption of fault currents. The breaker features a compact 1-inch by 1-inch by 1-inch frame with a 0.1 lb weight, constructed with a thermoplastic housing and a thermal-magnetic trip mechanism. It complies with UL 489 and CSA C22.2 standards for safety and performance. Typical applications include branch circuit protection in panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, thermoplastic housing
  • Voltage Rating: 240V AC
  • Current Rating: 15A
  • Dimensions: 1 in x 1 in x 1 in (Length/Depth x Height x Width)
  • Weight: 0.1 lb
  • Standards: UL 489, CSA C22.2
  • Applications: Branch circuit protection in panelboards, switchboards, motor control centers
  • Phase: 1
  • Poles: 1
  • AIC Rating: 10kA @ 240V AC
  • Connection: Line and load terminals
  • Protection: Overcurrent and short-circuit
  • Frame Size: HQP
  • Trip Type: Thermal-magnetic
  • Breaker Type: HQP
  • Mounting: Panel mount
  • Hz: 50/60
  • Wire Size: #14 to #8 AWG
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Pressure plate
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-phase
  • Installation Type: Fixed
  • Item QTY: 1
  • Breaker Frame: HQP
  • Current Rating: 15A
  • Operating Temperature Maximum Celsius: 40°C


Product Identification
  • UPC: 78667930457
  • GTIN: 00786679304570
