The Square D HOMT230240 is a 2-pole molded case circuit breaker from the HOMELINE family, designed to provide overcurrent protection for residential and light commercial branch circuits. This thermal-magnetic breaker is rated for 240V AC, 40A, with a 10kA interrupting capacity at 240V, and features both long-time and instantaneous trip functions to handle overloads and short circuits. Measuring 3.13 in (79.50 mm) in height, 1.97 in (50.04 mm) in width, and 3.29 in (83.57 mm) in depth, and weighing 0.85 lb, it uses a plug-in connection and accepts wire sizes from AWG 14 to AWG 8 (copper) or AWG 14 to AWG 6 (aluminum/copper). Manufactured by Schneider Electric in Mexico, it operates within a temperature range of -13 to 158 °F (-25 to 70 °C) and is suitable for single-phase applications in HOMELINE load centers and panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker (HOMT)
  • Voltage Rating: 240V AC
  • Current Rating: 40A
  • Poles: 2
  • Phase: 1
  • Connection: Plug-In
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC Rating: 10kA@240V
  • Wire Size: 1x AWG 14 to AWG 8, 1x AWG 14 to AWG 6 (Aluminum/Copper)
  • Dimensions: 3.13 in (79.50 mm) x 1.97 in (50.04 mm) x 3.29 in (83.57 mm) (H x W x D)
  • Weight: 0.85 lb
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Family: HOMELINE
  • Country of Origin: Mexico
  • Manufacturer: Schneider Electric


Product Identification
  • UPC: 785901041009
  • GTIN: 785901041009
