Siemens HNF461 - Fusible Disconnect Switch 600V/30A (200kA AIC @600V)

Siemens HNF461 is a fusible safety disconnect switch designed for industrial power distribution protection. It features a 600V AC voltage rating and 30A current capacity with a 200kA interrupting rating at 600V for robust short-circuit protection. The switch has a rugged NEMA 1 enclosure with a single-configuration, 4-pole design weighing 52 lb, constructed for durability in demanding environments. It complies with industry standards for fusible disconnects and is part of Siemens' VBII Series, manufactured in Mexico. Typical applications include motor control centers, HVAC systems, and industrial machinery requiring reliable circuit isolation.

Key Features & Specifications

• Type: Fusible safety disconnect switch (HNF type)
• Voltage Rating: 600V AC
• Current Rating: 30A
• Configuration: Single
• Poles: 4
• AIC Rating: 200kA@600V
• Fuse Class: R
• Phase: 3
• NEMA Rating: 1
• Compatible Frames: PGP
• Weight: 52 lb
• Switch Style: Fusible
• Standards: Industrial safety disconnects
• Applications: Motor control centers, industrial machinery, HVAC systems

Product Identification

• UPC: 783643488403
• GTIN: 00783643488403
