Cutler Hammer HMCP003A0CA05 - Motor Circuit Protector 3A 600VAC
Cutler Hammer HMCP003A0CA05 - Motor Circuit Protector 3A 600VAC

Cutler Hammer HMCP003A0CA05 - Motor Circuit Protector 3A 600VAC

Cutler Hammer
Price
Save $760.61
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Cutler Hammer HMCP003A0CA05 is a motor circuit protector designed for branch circuit protection of motor loads. This unit is rated for 3 amps at 600 VAC maximum, providing precise overload and short-circuit protection for industrial motor applications. The device features a compact 3.38-inch depth, 6-inch height, and 4.13-inch width, weighing 4.5 lb, with a molded case construction suitable for panel mounting. It complies with UL 489 and CSA standards, ensuring reliable performance in demanding environments. Typical applications include protecting motors in conveyors, pumps, and compressors within manufacturing and processing facilities.

Key Features & Specifications
  • Type: Motor circuit protector, molded case, thermal-magnetic trip
  • Voltage Rating: 600 VAC
  • Current Rating: 3 A
  • Dimensions: 3.38 in x 6 in x 4.13 in (L x H x W)
  • Standards: UL 489, CSA
  • Applications: Motor branch circuit protection for conveyors, pumps, compressors
  • Switch Type: Thermal-magnetic
  • Configuration: 3-pole
  • Coil Voltage Maximum: Not applicable
  • Temp Rating: 40°C
  • Shipping Dimensions: 3.38 in x 6 in x 4.13 in
  • Phase: 3-phase
  • Voltage: 600 VAC
  • Amperage: 3 A
  • AIC rating: 65 kA at 240 VAC, 25 kA at 480 VAC, 18 kA at 600 VAC
  • Connection: Line and load terminals
  • Poles: 3
  • Protection: Overload and short-circuit
  • Functions: Motor circuit protection
  • Frame Size: C-frame
  • Trip Type: Thermal-magnetic
  • Panel Type: Industrial panel
  • Breaker Type: Motor circuit protector
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Molded case
  • Panel Style: Fixed
  • Bus Type: Not applicable
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Panel mount
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: 1 HP at 240 VAC, 2 HP at 480 VAC, 3 HP at 600 VAC
  • Aux Contacts: Not included
  • CPT: Not included
  • Full Load Amps: 3 A
  • Dist Voltage: Not applicable
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 3 A
  • Full Load Amp Minimum: 3 A
  • Enclosure: Open style
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not applicable
  • Amperage Maximum: 3 A
  • Amperage Minimum: 3 A
  • Nema Rating: 1
  • Switch Style: Not applicable
  • Wire Size: 14 AWG to 8 AWG
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Panel mount
  • Terminal Connection: Screw terminals
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-phase
  • Standards: UL 489, CSA C22.2
  • Compatible Frames: C-frame
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: C-frame
  • Current Rating: 3 A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 78667909593
  • GTIN: 00786679095935
