Square D HLL26050 - Molded Case Circuit Breaker 50A 600V 2-Pole
Square D HLL26050 - Molded Case Circuit Breaker 50A 600V 2-Pole

Square D HLL26050 - Molded Case Circuit Breaker 50A 600V 2-Pole

Square D
Price
Save $1,924.12
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D HLL26050 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 50A current rating and a 600V voltage rating, housed within a compact H-frame measuring 163 mm x 104 mm x 86 mm (HxWxD) and weighing 4.9 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous (LI) protection, ensuring compliance with UL, CSA, NEMA, NOM, and IEC 60947-2 standards. Its feed-thru connection and ability to accept wire sizes from AWG 14 to 3/0 make it suitable for a wide range of commercial and industrial panel applications, operating effectively in ambient temperatures from -2 to 70 °C.

Key Features & Specifications
  • Type: HLL Series Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 50A
  • Dimensions: 6.4 in H x 4.09 in W x 3.4 in D (163 mm x 104 mm x 86 mm)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial Power Distribution, Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Temp Rating: 28 to 158 °F (-2 to 70 °C)
  • Phase: 1
  • Amperage: 50A
  • AIC Rating: 100kA @ 480V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: H Frame
  • Wire Size: AWG 14 to AWG 3/0 (aluminium/copper terminal)
  • Certification: UL, CSA, NOM
  • Family: Powerpact
  • Country of Origin: Mexico
  • Weight: 4.9 lb


Product Identification
  • UPC: 785901934769
  • GTIN: 00785901934769
