Square D HLL26030 - Molded Case Circuit Breaker, 30A 600V 2-Pole
Square D HLL26030 - Molded Case Circuit Breaker, 30A 600V 2-Pole

Square D HLL26030 - Molded Case Circuit Breaker, 30A 600V 2-Pole

Square D
Price
Save $673.59
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D HLL26030 is a Powerpact H-frame molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection for industrial electrical systems. It features a 30A current rating and a 600V AC voltage rating, with a robust thermal-magnetic trip unit providing both long-time and instantaneous (LI) protection functions. The compact unit measures 163 mm H x 104 mm W x 86 mm D and weighs 4.9 lb, featuring a two-pole, feed-thru connection design compatible with AWG 14 to 3/0 aluminum or copper conductors. It is engineered to comply with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, ensuring suitability for a wide range of commercial and industrial power distribution applications where a 100kA interrupting capacity at 480V is required.

Key Features & Specifications
  • Type: HLL Series, Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 30A
  • Dimensions: 6.4 in (163 mm) H x 4.09 in (104 mm) W x 3.4 in (86 mm) D
  • Weight: 4.9 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification: UL, CSA, NOM
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: H Frame
  • Poles: 2
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • Wire Size: AWG 14...AWG 3/0 aluminium/copper terminal
  • AIC Rating: 100kA @ 480V
  • Phase: 1
  • Temp Rating: 28-158 °F (-2-70 °C)
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901659181
  • GTIN: 00785901659181
