Square D HL2IMA24C - 60A Thermal Magnetic Breaker (208Y/120VAC)
Square D HL2IMA24C - 60A Thermal Magnetic Breaker (208Y/120VAC)

Square D HL2IMA24C - 60A Thermal Magnetic Breaker (208Y/120VAC)

Square D
Price
Save $4,485.46
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D HL2IMA24C is a thermal magnetic circuit breaker designed for overcurrent and short-circuit protection in industrial power distribution systems. It operates at 208Y/120VAC with a 60A current rating and features a 3-pole I-Line connection for secure panel mounting. This unit measures 12.2 in x 13.5 in x 5.6 in (308.9 mm x 341.9 mm x 142.1 mm) and weighs 22.187 lb, constructed with copper wire rated for 6 AWG. It complies with UL 1449 ed. 3, UL 1283 ed. 5, CSA C22.2 No 8:1986, UL 96A ed. 12, UL 489 ed. 11, and CSA C22.2 No 5-09, with UL, CSA, and NEMA certifications. Typical applications include surge protection in 3-phase commercial and industrial electrical panels.

Key Features & Specifications
  • Type: HL thermal magnetic circuit breaker with I-Line connection
  • Voltage Rating: 208Y/120VAC
  • Current Rating: 60A
  • Dimensions: 12.2 in (308.9 mm) x 13.5 in (341.9 mm) x 5.6 in (142.1 mm) (Height x Width x Depth)
  • Standards: UL 1449:ed. 3, UL 1283:ed. 5, CSA C22.2 No 8:1986, UL 96A:ed. 12, UL 489:ed. 11, CSA C22.2 No 5-09
  • Applications: Surge protection in 3-phase industrial panels
  • Poles: 3
  • Connection: I-Line
  • Protection: Thermal Magnetic
  • Wire Size: 6 AWG, Copper
  • Certification: UL, CSA, NEMA
  • Phase: 3
  • Section: Surge Protection
  • Weight: 22.187 lb
  • Country of Origin: Mexico
  • Family: SURGELOGIC
  • Item Subcategory: Parts And Accessories


Product Identification
  • UPC: 785901851431
