Square D HGP36000S15 - 150A 3-Pole Molded Case Switch (600V)
Square D HGP36000S15 - 150A 3-Pole Molded Case Switch (600V)

Square D HGP36000S15 - 150A 3-Pole Molded Case Switch (600V)

Square D
Price
Save $1,140.71
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
The Square D HGP36000S15 is a 3-pole, 150A molded case circuit breaker designed for use as a non-automatic switch, providing no overcurrent protection. It is rated for 600V AC, 3-phase systems, with an interrupting capacity of 35kA at 480V AC. This bolt-on unit measures 6.4 inches in height, 2.12 inches in width, and 4.36 inches in depth, weighing 5 lb. It is manufactured in the United States by Schneider Electric and complies with applicable industry standards for industrial switching applications. Typical uses include serving as a disconnect switch in panelboards, switchboards, and other power distribution equipment where manual load control is required without integral circuit protection.

Key Features & Specifications
  • Type: Molded Case, Non-Automatic
  • Voltage Rating: 600V AC
  • Current Rating: 150A
  • Dimensions: 6.4 in (162.6 mm) x 2.12 in (53.85 mm) x 4.36 in (110.74 mm) (Height x Width x Depth)
  • Standards: UL, CSA
  • Applications: Industrial disconnect, power distribution
  • Switch Type: Non-Automatic
  • Configuration: 3-Pole
  • Phase: 3
  • Amperage: 150A
  • AIC rating: 35kA@480V
  • Connection: Bolt-On
  • Protection: No Overcurrent Protection
  • Functions: NA
  • Frame Size: HGP
  • Breaker Type: HGP36000S15
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Bolt-On
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Installation Type: Fixed
  • Item QTY: 1
  • Breaker Frame: HGP
  • Current Rating: 150A
  • Operating Temperature Maximum Celsius: 40°C


Product Identification
  • UPC: 785901643425
