Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P
Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P

Square D HGL26030 - Molded Case Circuit Breaker 30A 600V 2P

Square D
Price
Save $758.20
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Square D HGL26030 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 30A current rating and a 600V voltage rating, housed within a compact 150A/HG frame with dimensions of 163 mm H x 104 mm W x 86 mm D and a weight of 3.04 lb. This thermal magnetic, bolt-on, two-pole breaker is constructed for an operating temperature range of -25 to 70 °C and complies with UL, CSA, NEMA, NOM, and IEC 60947-2 standards. It is typically applied in panelboards and switchboards, offering a 35kA interrupting capacity at 480V for robust system protection.

Key Features & Specifications
  • Type: Standard thermal magnetic molded case circuit breaker with long-time and instantaneous trip functions
  • Voltage Rating: 600V AC
  • Current Rating: 30A
  • Dimensions: 163 mm H x 104 mm W x 86 mm D (6.4 in x 4.09 in x 3.4 in)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial panelboards and switchboards
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC Rating: 35kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous
  • Frame Size: 150A/HG
  • Breaker Type: Standard
  • MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 3 AWG
  • Terminal Connection: Line/Load Lug
  • Wire Size: AWG 14 to AWG 3/0 aluminium/copper terminal
  • Certification: UL, CSA, NOM
  • Phase Connection: Not Applicable


Product Identification
  • UPC: 785901683254
  • GTIN: 00785901683254
